Anycast DNS - Using BGP

/ DNS, BIND, Anycast, DDI

Anycast DNS

In this fifth article on Anycast DNS, we provide some examples of deploying Anycast using Border Gateway Protocol or BGP, the core routing protocol of the Internet.

While BGP is mostly used by Internet Service Providers (ISPs), it is also used in some of the larger enterprise environments that must interconnect networks that span geographical and/or administrative regions and boundaries. Since BGP is a very complex routing protocol, we will provide only a basic recipe using Cisco and Quagga host-based routing software. A detailed discussion of the BGP protocol is beyond the scope of th...

Read More...

Anycast DNS

In this continuation of the fourth article, we improve the design with enhanced security, performance, and efficiency.

Our configuration consists of two OSPF areas 51 and 52, containing an Anycast DNS server, and pair of Cisco Routers connected to the backbone area 0.0.0.0. The Anycast DNS servers are configured with Quagga, running the OSPF routing protocol engine, this is used to advertise our two (2) Anycast DNS VIPs, 192.168.0.1/32 and 192.168.1.1/32 into the OSPF routed network. The diagram below focuses on our "fictitious" area 51:

Anycast DNS using OSPF layout

As mentioned, we'll provide additional "...

Read More...

Anycast DNS Using OSPF

/ DNS, BIND, Anycast, DDI

Anycast DNS

The fourth article in our Anycast DNS series covers Anycast DNS using Open Shortest Path First or OSPF routing protocol.

OSPF is a dynamic routing protocol used to build larger scale IP networks. It differs from RIP, because it is a link-state routing protocol and falls into the group of Interior Gateway Protocols that operate within a single Autonomous System or AS. OSPF is a link-state routing protocol that runs Dijkstra's algorithm to calculate the shortest path to other networks. Taking the bandwidth of the network links into account, it uses cost as its metric. OSPF works by devel...

Read More...

Anycast DNS

The third article in the Anycast DNS series continues our discussion of implementing Anycast DNS using RIPv2

This article is a continuation of Anycast DNS using RIP in our series on Anycast DNS. In this next recipe, two Anycast VIPs will be advertised on two (2) DNS servers that are multi-homed on different subnets by different routers using RIP v2. In this recipe, we'll review the commands that will be needed to add the additional interfaces to our Quagga configuration, as well as, briefly discuss how to handle multiple default gateways on multi-homed hosts. The figure below depicts...

Read More...

Anycast DNS Using RIP

/ DNS, BIND, Anycast, DDI

Anycast DNS

This third article in our series on Anycast DNS, focuses on deploying Anycast DNS using RIP v2 routing protocol.

In this article we'll be using Quagga, Open Source host-based routing software, to originate our Anycast IP address. Our upstream routers are Cisco routers, so we'll also be providing all routing configurations that are needed for the recipes. The goal of the recipe is to be efficient, secure, and simple.

In this recipe we configure a single Anycast VIP on two name servers, using host-based routing software to originate the routes Anycast VIPs to their upstream routers via...

Read More...

Anycast DNS

This second article in our series "Anycast DNS" is a recipe for deploying Anycast DNS using static routes.

In this article we'll show our recipe for configuring Anycast using static routes, and provide an explanation as to why this is the least optimal way of building an Anycast DNS environment.

Recipe - Single Anycast IP Address 192.168.0.1/32

The goal of this recipe is to configure Anycast DNS on two (2) Linux caching only DNS servers. While this solution can accommodate additional servers, we'll only deal with two servers in our scenario. Our fictitious company, ABC Corporation,...

Read More...

Anycast DNS - Overview

/ DNS, BIND, Anycast, DDI

Anycast DNS

This is the first article in series on the topic of deploying Anycast DNS.

The purpose of this series of articles is to share some ideas, recipes, and information on how to deploy Anycast in your environment.  The first thing we need to do is explain what Anycast is.  Anycast is the use of routing and addressing policies to affect the most efficient path between a single source and several geographically dispersed targets that "listen" to a service within a receiver group.  In Anycast, the same IP address space is used to address each of the listening targets (DNS servers in our case)....

Read More...
